MSI MAG B550M Mortar Max Wi-Fi AM4 AMD Motherboard
Regular Price: BDT 21,120.00
* অনলাইন থেকে প্রডাক্ট অর্ডার এর পূর্বে হেল্পলাইন থেকে স্টক এবং ডেলিভারী সম্পর্কে সঠিকভাবে জেনে অর্ডার করার জন্য বিশেষভাবে অনুরোধ করা হচ্ছে * 01965656300
- Brand: MSI
- Model: MAG B550M MORTAR MAX WIFI
- Supported CPU: Ryzen 5000, 5000 G, 4000G, and 3000 Series processors
- Supported RAM: 4x DDR4, up to 128GB, 4400+(OC) MHz
- Graphics Output: 1x HDMI, 1x DisplayPort
- Features: Realtek RTL8125B 2.5G LAN
|
Basic Info |
|
|
Brand Name |
MSI |
|
Model No. |
MAG B550M Mortar Max Wi-Fi |
|
CPU Details |
|
|
Chipset Brand |
AMD |
|
Chipset Model |
AMD B550 Chipset |
|
CPU Supported |
Supports AMD Ryzen 5000 Series, 5000 G-Series, 4000G-Series, and 3000 Series processors |
|
Memory |
|
|
Memory Type |
DDR4 |
|
Memory MHz |
Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC |
|
Channel |
Dual |
|
Slot |
4 x DDR4 |
|
Max. Memory |
128GB |
|
Storage |
|
|
Storage Interface |
AMD B550 Chipset |
|
Graphics Info |
|
|
Graphics |
1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz |
|
Max Shared Memory |
16 GB |
|
PCI Express Slot |
1x PCIe 3.0/ 4.0 x16 slot (PCI_E1) |
|
Ports & Connectivity |
|
|
USB Port |
3x USB 3.2 Gen 1 5Gbps ports (1 Type-C internal connector and 2 ports are available through the internal USB 3.2 Gen 1 5Gbps connector) |
|
Internal I/O Ports |
1x 24-pin ATX main power connector |
|
Others |
|
|
Audio |
Realtek ALC1200 Codec |
|
Form Factor |
Micro-ATX Form Factor |
|
OS Support |
Windows 10/11 |
|
Warranty |
|
|
Warranty |
3 Years Replacement Warranty |
Description
MSI MAG B550M Mortar Max Wi-Fi AM4 AMD Motherboard
The MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MAG series has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.The MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MSI MAG B550M Mortar Max Wi-Fi AM4 AMD Motherboard has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.
HIGH-BANDWIDTH AND LOW-LATENCY NETWORK
2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.
MAG B550M MORTAR MAX WIFI
- Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000G-Series, and 3000 Series processors
- Supports DDR4 Memory, up to 4400+(OC) MHz
- Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, AMD Turbo USB 3.2 Gen 2
- Premium Thermal Solution: Extended Heatsink Design with additional choke thermal pad rated for 7W/mk and PCB with 2oz thickened copper are built for high performance system and non-stop gaming experience.
- Enhanced Power Design: 8+2+1 Duet Rail Power System, Digital PWM, Core Boost, DDR4 Boost.
- 2.5G LAN with LAN Manager and AMD Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection.
- Pre-installed I/O Shield: Better EMI protection and more convenience for installation.
- Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience.
- Multi-GPU: With Steel Armor PCI-E slots. Supports AMD Crossfire™
OPTIMIZED FOR WATER COOLING
Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation and a perfect fit.
MSI MAG B550M Mortar Max Wi-Fi AM4 AMD Motherboard
The MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MAG series has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.The MAG series was born through rigorous quality testing and designed to be a symbol of sturdiness and durability. Focused on providing the best user experience, the MSI MAG B550M Mortar Max Wi-Fi AM4 AMD Motherboard has a simple installation process coupled with a friendly user interface making it the best choice for entry level gamers.2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.
HIGH-BANDWIDTH AND LOW-LATENCY NETWORK
2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.
MAG B550M MORTAR MAX WIFI
- Supports AMD Ryzen™ 5000 Series, 5000 G-Series, 4000G-Series, and 3000 Series processors
- Supports DDR4 Memory, up to 4400+(OC) MHz
- Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, AMD Turbo USB 3.2 Gen 2
- Premium Thermal Solution: Extended Heatsink Design with additional choke thermal pad rated for 7W/mk and PCB with 2oz thickened copper are built for high performance system and non-stop gaming experience.
- Enhanced Power Design: 8+2+1 Duet Rail Power System, Digital PWM, Core Boost, DDR4 Boost.
- 2.5G LAN with LAN Manager and AMD Wi-Fi 6E Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection.
- Pre-installed I/O Shield: Better EMI protection and more convenience for installation.
- Audio Boost: Reward your ears with studio grade sound quality for the most immersive gaming experience.
- Multi-GPU: With Steel Armor PCI-E slots. Supports AMD Crossfire™
OPTIMIZED FOR WATER COOLING
Designed to support the most popular All-In-One & customized water cooling solutions on the market. A dedicated water pump PIN header supports up to 3 amp, giving you full control of the water pump speed. A clearly marked ‘keep-out-zone’ allows for easy and safe installation and a perfect fit.
