Basic Info

Brand Name

Asus

Model No.

CPU Details

Chipset Brand

Intel

Chipset Model

Intel B460

CPU  Supported

Intel Socket 1200 for 10th Gen Intel Core, Pentium Gold and Celeron Processors
Supports Intel 14 nm CPU
Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0

Generation

10^th/ 11^th Generation

Memory

Memory Type

DDR4

Memory MHz

2933/ 2800/ 2666/ 2400/ 2133 MHz

Channel

Dual

Slot

4 x DIMM

Max. Memory

128GB

Storage

Storage Interface

Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
Intel B460 Chipset :
1 x M.2 Socket 3, with M key, type 2242/ 2260/ 2280 storage devices support (both SATA & PCIE mode)
1 x M.2 Socket 3, with M Key, type 2242/ 2260/ 2280 storage devices support (x4 PCIE mode)
6 x SATA 6Gb/s port(s)
Support Raid 0, 1, 5, 10
Intel Rapid Storage Technology supports
Intel Optane Memory Ready

Graphics Info

PCI Express Slot

16-Lane CPU
1 x PCIe 3.0/2.0 x16 (x16 mode)
Intel B460 Chipset
2 x PCIe 3.0/2.0 x1
1 x PCI

Type

Integrated

Audio Chipset.

Realtek ALC887 7.1-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-recording, Front Panel Jack-retasking, up to 24-Bit/ 192kHz playback

Ports & Connectivity

USB Port

Rear USB Port ( Total 6 )
4 x USB 3.2 Gen 1 port(s) (4 x Type-A)
2 x USB 2.0 port(s) (2 x Type-A)
Front USB Port ( Total 6 )
2 x USB 3.2 Gen 1 port(s)
4 x USB 2.0 port(s)

Back Ports

1 x CPU Fan connector(s) (1 x 4 -pin)
2 x Chassis Fan connector(s) (2 x 4 -pin)
1 x MONO out header (with Amp IC)
1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)
2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
1 x M.2 Socket 3 with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode)

Bios & Technical Info

BIOS Type

128Mb Flash ROM, UEFI AMI BIOS

Form Factor

mATX Form Factor
9.6 inch x 9.6 inch ( 24.4 cm x 24.4 cm )

OS Support

Windows 10

Warranty

Warranty

3 Years Replacement Warranty
